STEGO温湿度一体控制器ETF012 230VAC 01230.0-00

STEGO温湿度一体控制器ETF012 230VAC 01230.0-00

详细信息

品牌：stego	型号：ETF012	加工定制：是
类型：数字式	温度范围：0-60 ℃	湿度范围：55-95
测量精度：0.01	测量误差：0.01 ℃	精度等级：1
分辨率：100	尺寸：251515 mm	重量：0.25 kg
适用范围：机柜

上海含灵机械设备有限公司现货销售STEGO温湿度一体控制器ETF012 230VAC 01230.0-00

stego温控器，stego照明灯， stego压力缓冲装置

TECHNICAL DATA

Switch difference (temperature)Switch difference (humidity)Reaction time (humidity)Contact typeService lifeMax. switching capacity (relay output)Max. inrush currentOptical indicatorConnectionMountingCasingDimensionsWeightFitting positionOperating/Storage temperatureOperating/Storage humidityProtection typeApprovals
STEGO温湿度一体控制器ETF012 230VAC 01230.0-00

2K (±1K tolerance) at +25°C (+77°F), 50% RH

4% RH (±1% tolerance) at +25°C (+77°F), 50% RH

approx. 5 sec.

change-over contact (relay)

VDE: NO/NC > 15,000 cycles
UL: NO/NC > 30,000 cycles

240VAC, 10 (1.6) A
60VDC, 0.6A¹

AC 30A for 10 sec.

LED

5-pole terminal, clamping torque 0.5Nm max.:
rigid/stranded² wire 2.5mm² (AWG 14)

clip for 35mm DIN rail, EN 60715

plastic according to UL94 V-0, light grey

77 x 60 x 43mm

approx. 0.2kg

vertical

-40 to +60°C (-40 to +140°F)

max. 90% RH (non-condensing)

IP20

VDE, UL File No. E164102, EAC

¹ not UL confirmed

² When connecting with stranded wires, wire end ferrules must be used.

Art. No.Operating voltageSetting range temperatureSetting range humidity

01230.0-00

100-240VAC, 50/60Hz (min. 90VAC, max. 265VAC)

0 to +60°C

50 to 90% RH

01230.9-00

100-240VAC, 50/60Hz (min. 90VAC, max. 265VAC)

+32 to +140°F

50 to 90% RH

01230.1-00

- KTO 011 / KTS 011 | NC (Heating) or NO (Cooling) - Standard
- STO 011 / STS 011 | NC (Heating) or NO (Cooling) - Small Hysteresis
- FTO 011 / FTS 011 | NC (Heating) or NO (Cooling) - Tamper-proof
- ZR 011 | Combination: NC/NO
- FTD 011 | Combination: NC/NO - Tamper-proof
- FZK 011 | Change-over Contact (Heating/Cooling)
- ETR 011 | Electronic Thermostat
- ETL 011 | Electronic Thermostat (DC, low signals)
- ET 011 | Electronic Thermostat (24VDC)
- MFR 012 | Mechanical Hygrostat
- EFR 012 | Electronic Hygrostat
- EFL 012 | Electronic Hygrostat (DC, low signals)
- ETF 012 | Hygrotherm
- ETF 012 | Hygrotherm with external sensor
- SM 010 | Switch Module (24VDC and 48VDC)
- DCM 010 | Switch Module (DC 20V to 56V)
- DCT 010 | Electronic Thermostat (DC 20V to 56V)
- DCF 010 | Electronic Hygrostat (DC 20V to 56V)
Hazardous Area Thermostat

24-48VDC (min. 20VDC, max. 60VDC)

0 to +60°C

50 to 90% RH
